Powersport Battery Specifications
Rated Operating Temperature -40°F (-40°C) to 113°F (45°C) Metal Jacket (MJ) Option increases rated operating temperature to 176°F (80°C)
All values shown are nominal unless otherwise noted.
| NEW PART NUMBER (Old Part Number) |
Voltage | PHCA** 5 sec. [A] |
CCA* [A] |
HCA* [A] |
MCA* [A] |
20 HR Rate [Ah] |
10 HR Rate [Ah] |
Reserve Capacity [Minutes] |
Maximum Length [in (mm)] |
Maximum Width [in (mm)] |
Maximum Total Height [in (mm)] |
Maximum Container Height [in (mm)] |
Weight [lb (kg)] |
Terminal | Maximum Torque [in-lb (Nm)] |
Internal Resistance [mΩ] |
Terminal Layout |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ODS-AGM28LA (PC925T) |
12 | 900 | 330 | 610 | 480 | 28 | 27 | 48 | 6.57 (167) |
6.92 (176) |
5.77 (147) |
4.96 (126) |
23.8 (10.8) |
SAE | N/A | 5 | View |
 ODS-AGM6M (PC2250) |
12 | 2250 | 1225 | 1730 | 1550 | 126 | 114 | 240 | 11.26 (286) |
10.59 (269) |
9.17 (233) |
9.17 (233) |
86 (39.0) |
SAE and 3/8-16" Stud | 100 (11.3) stud only | 2.1 | View |
 ODS-AGM8E (PC310) |
12 | 310 | 100 | 200 | 155 | 8 | 7 | 9 | 5.43 (138) |
3.39 (86) |
3.9 (99) |
3.90 (99) |
5.9 (2.7) |
M4 Receptacle | 8.9 (1.0) | 27.1 | View |
 ODS-AGM70S (PC1700S) |
12 | 1550 | 810 | 1325 | 1175 | 68 | 65 | 142 | 13.02 (331) |
6.62 (168) |
7.37 (187) |
6.93 (176) |
60.9 (27.6) |
5/16-18" Stud | 60 (6.8) | 3.5 | View |
 ODS-AGM70MJS (PC1700MJS) |
12 | 1550 | 810 | 1325 | 1175 | 68 | 65 | 142 | 13.03 (331) |
6.63 (168) |
7.41 (188) |
6.97 (177) |
60.9 (27.6) |
5/16-18" Stud | 60 (6.8) | 3.5 | View |
 ODS-AGM70MJA (PC1700MJT) |
12 | 1550 | 810 | 1325 | 1175 | 68 | 65 | 142 | 13.03 (331) |
6.63 (168) |
7.78 (198) |
6.97 (177) |
60.9 (27.6) |
SAE | N/A | 3.5 | View |
 ODS-AGM70MJ (PC1700MJ) |
12 | 1550 | 810 | 1325 | 1175 | 68 | 65 | 142 | 13.03 (331) |
6.63 (168) |
6.65 (169) |
6.97 (177) |
60.9 (27.6) |
M6 Receptacle | 60 (6.8) | 3.5 | View |
 ODS-AGM70A (PC1700T) |
12 | 1550 | 810 | 1325 | 1175 | 68 | 65 | 142 | 13.02 (331) |
6.62 (168) |
7.75 (197) |
6.93 (176) |
60.9 (27.6) |
SAE | N/A | 3.5 | View |
 ODS-AGM70 (PC1700) |
12 | 1550 | 810 | 1325 | 1175 | 68 | 65 | 142 | 13.02 (331) |
6.62 (168) |
6.61 (168) |
6.93 (176) |
60.9 (27.6) |
M6 Receptacle | 60 (6.8) | 3.5 | View |
 ODS-AGM470FTT (PC1800-FT) |
12 | 1800 | 1300 | 1600 | 1450 | 214 | 190 | 475 | 22.87 (581) |
4.92 (125) |
12.46 (316) |
12.46 (316) |
132.3 (60.0) |
3/8-16" Stud | 80 (9.0) | 3.3 | View |
 ODS-AGM42MJA (PC1200LMJT) |
12 | 1200 | 540 | 860 | 725 | 42 | 40 | 78 | 7.87 (200) |
6.66 (169) |
7.6 (193) |
6.80 (173) |
38.2 (17.3) |
SAE | N/A | 4.5 | View |
 ODS-AGM42LMJA (PC1200MJT) |
12 | 1200 | 540 | 860 | 725 | 42 | 40 | 78 | 7.87 (200) |
6.66 (169) |
7.6 (193) |
6.80 (173) |
38.2 (17.3) |
SAE | N/A | 4.5 | View |
 ODS-AGM42LMJ (PC1200MJ) |
12 | 1200 | 540 | 860 | 725 | 42 | 40 | 78 | 7.87 (200) |
6.66 (169) |
6.46 (164) |
6.81 (173) |
38.2 (17.3) |
M6 Receptacle | 60 (6.8) | 4.5 | View |
 ODS-AGM42LA (PC1200T) |
12 | 1200 | 540 | 860 | 725 | 42 | 40 | 78 | 7.78 (198) |
6.53 (166) |
7.54 (192) |
6.72 (171) |
38.2 (17.3) |
SAE | N/A | 4.5 | View |
 ODS-AGM42L (PC1200) |
12 | 1200 | 540 | 860 | 725 | 42 | 40 | 78 | 7.78 (198) |
6.53 (166) |
6.40 (163) |
6.72 (171) |
38.2 (17.3) |
M6 Receptacle | 60 (6.8) | 4.5 | View |
 ODS-AGM42A (PC1200LT) |
12 | 1200 | 540 | 860 | 725 | 42 | 40 | 78 | 7.78 (198) |
6.53 (166) |
7.54 (192) |
6.72 (171) |
38.2 (17.3) |
SAE | N/A | 4.5 | View |
 ODS-AGM40E (PC1100) |
12 | 1100 | 500 | 800 | 650 | 45 | 43 | 87 | 9.84 (250) |
3.82 (97) |
8.11 (206) |
7.71 (196) |
27.5 (12.5) |
M6 Stud | 35 (3.9) | 5.1 | View |
 ODS-AGM30E (PC950) |
12 | 950 | 400 | 600 | 500 | 34 | 32 | 60 | 9.84 (250) |
3.82 (97) |
6.14 (156) |
5.75 (146) |
20 (9.1) |
M6 Stud | 35 (3.9) | 7.1 | View |
 ODS-AGM28MJA (PC925LMJT) |
12 | 900 | 330 | 610 | 480 | 28 | 27 | 48 | 6.64 (169) |
7.05 (179) |
5.83 (148) |
5.04 (128) |
23.8 (10.8) |
SAE | N/A | 5 | View |
 ODS-AGM28MJ (PC925LMJ) |
12 | 900 | 330 | 610 | 480 | 28 | 27 | 48 | 6.64 (169) |
7.05 (179) |
4.77 (121) |
5.04 (128) |
23.8 (10.8) |
M6 Receptacle | 60 (6.8) | 5 | View |
 ODS-AGM28LMJA (PC925MJT) |
12 | 900 | 330 | 610 | 480 | 28 | 27 | 48 | 6.64 (169) |
7.05 (179) |
5.83 (148) |
5.04 (128) |
23.8 (10.8) |
SAE | N/A | 5 | View |
 ODS-AGM28LMJ (PC925MJ) |
12 | 900 | 330 | 610 | 480 | 28 | 27 | 48 | 6.64 (169) |
7.05 (179) |
4.77 (121) |
5.04 (128) |
23.8 (10.8) |
M6 Receptacle | 60 (6.8) | 5 | View |
 ODS-AGM28L (PC925) |
12 | 900 | 330 | 610 | 480 | 28 | 27 | 48 | 6.57 (167) |
6.92 (176) |
4.7 (119) |
4.96 (126) |
23.8 (10.8) |
M6 Receptacle | 60 (6.8) | 5 | View |
 ODS-AGM28 (PC925L) |
12 | 900 | 330 | 610 | 480 | 28 | 27 | 48 | 6.57 (167) |
6.92 (176) |
4.7 (119) |
4.96 (126) |
23.8 (10.8) |
M6 Receptacle | 60 (6.8) | 5 | View |
 ODS-AGM16LMJA (PC680MJT) |
12 | 520 | 170 | 350 | 280 | 16 | 16 | 24 | 7.27 (185) |
3.11 (79) |
7.55 (192) |
6.67 (169) |
15.4 (7.0) |
SAE | N/A | 7 | View |
 ODS-AGM16LMJ (PC680MJ) |
12 | 520 | 170 | 350 | 280 | 16 | 16 | 24 | 7.27 (185) |
3.11 (79) |
6.43 (163) |
6.67 (169) |
15.4 (7.0) |
M6 Receptacle | 50 (5.6) | 7 | View |
 ODS-AGM16L (PC680) |
12 | 520 | 170 | 350 | 280 | 16 | 16 | 24 | 7.15 (182) |
3.01 (76) |
6.36 (162) |
6.61 (168) |
15.4 (7.0) |
M6 Receptacle | 50 (5.6) | 7 | View |
 ODS-AGM16CL (PC625) |
12 | 540 | 220 | 400 | 330 | 18 | 17 | 26 | 6.7 (170) |
3.9 (99) |
6.95 (177) |
6.89 (175) |
13.2 (6.0) |
M6 Receptacle | 40 (4.5) | 7 | View |
 ODS-AGM16B (PC535) |
12 | 535 | 200 | 300 | 265 | 14 | 13 | 21 | 6.7 (170) |
3.9 (99) |
6.24 (158) |
6.18 (157) |
12 (5.4) |
M6 Receptacle | 40 (4.5) | 8 | View |
 ODS-AGM15LMJ (PC545MJ) |
12 | 460 | 150 | 280 | 220 | 13 | 12 | 18 | 7.02 (178) |
3.39 (86) |
4.92 (125) |
5.17 (131) |
11.4 (5.2) |
M6 Receptacle | 50 (5.6) | 10 | View |
 ODS-AGM15L (PC545) |
12 | 460 | 150 | 280 | 220 | 13 | 12 | 18 | 6.91 (176) |
3.29 (84) |
4.89 (124) |
5.12 (130) |
11.4 (5.2) |
M6 Receptacle | 50 (5.6) | 10 | View |
- *Cold Start Performance S.A.E J537 JUNE 82
- **Pulse Current
