Heavy Duty/Commercial Specifications

ODYSSEY Extreme Series Heavy Duty/Commercial batteries

MODEL Voltage PHCA**
(5 sec.)
CCA* HCA MCA Nominal Capacity Reserve Capacity Minutes Length inches
(mm)
Width inches
(mm)
Height inches
(mm)
Weight lbs
(kg)
Terminal Torque Specs in-lbs
(Nm max)
Internal Resistance
(mΩ)
Short Circuit Current
(20 Hr Rate-Ah) (10 Hr Rate-Ah)

ODS-AGM6M
(PC2250)
12 2250 1225 1730 1550 114 92 240 11.26
(286.00)
10.59
(268.99)
9.17
(232.92)
86
(39.01)
SAE and 3/8-16" Stud 100 (11.3) stud only 2.1 5000A

ODX-AGM65
(65-PC1750T)
12 1750 930 1350 1070 74 65 135 11.84
(300.74)
7.19
(182.63)
7.49
(190.25)
54
(24.49)
SAE N/A 2.0 5000A

ODX-AGM34R
(34R-PC1500T)
12 1500 850 1250 1050 68 62 134 10.86
(275.84)
6.77
(171.96)
7.87
(199.90)
49.5
(22.45)
SAE N/A 2.5 3100A

ODX-AGM34 78
(34-78-PC1500)
12 1500 850 1250 1050 68 62 134 10.86
(275.84)
6.77
(171.96)
7.88
(200.15)
49.5
(22.45)
SAE & Side 60 (6.8) Side terminal only 2.5 3100A

ODX-AGM34
(34-PC1500T)
12 1500 850 1250 1050 68 62 134 10.86
(275.84)
6.77
(171.96)
7.94
(201.68)
49.5
(22.45)
SAE N/A 2.5 3100A

ODX-AGM31R
(31R-PC2150S)
12 2150 1150 1545 1370 100 92 205 13.00
(330.20)
6.80
(172.72)
9.49
(241.05)
77.8
(35.29)
3/8-16" Stud 200 (22.6) studs only 2.2 5000A

ODX-AGM31A
(31-PC2150T)
12 2150 1150 1545 1370 100 92 205 13
(330.20)
6.8
(172.72)
9.67
(245.62)
77.8
(35.29)
SAE N/A 2.2 5000A

ODX-AGM31
(31-PC2150S)
12 2150 1150 1545 1370 100 92 205 13.00
(330.20)
6.80
(172.72)
9.49
(241.05)
77.8
(35.29)
3/8-16" Stud 200 (22.6) Studs only 2.2 5000A

ODX-AGM27F
12 1750 930 1290 1080 92 88 195 12.4
(314.96)
6.77
(171.96)
8.75
(222.25)
67.9
(30.80)
SAE N/A 2.6 5000A

ODX-AGM27
12 1750 930 1290 1080 92 88 195 12.4
(314.96)
6.77
(171.96)
8.75
(222.25)
67.9
(30.80)
SAE N/A 2.6 5000A

ODX-AGM24F
12 1500 840 1200 1000 76 73 160 10.87
(276.10)
6.77
(171.96)
8.75
(222.25)
57.1
(25.90)
SAE N/A 4.5 3100A

ODX-AGM24
12 1500 840 1200 1000 76 73 160 10.87
(276.10)
6.77
(171.96)
8.75
(222.25)
57.1
(25.90)
SAE N/A 4.5 3100A

ODYSSEY Performance Series Heavy Duty/Commercial batteries

MODEL Voltage PHCA**
(5 sec.)
CCA* HCA MCA Nominal Capacity Reserve Capacity Minutes Length inches
(mm)
Width inches
(mm)
Height inches
(mm)
Weight lbs
(kg)
Terminal Torque Specs in-lbs
(Nm max)
Internal Resistance
(mΩ)
Short Circuit Current
(20 Hr Rate-Ah) (10 Hr Rate-Ah)

ODP-AGM94R H7 L4
(94R-850)
12 1500 850 1200 1000 80 76 150 12.39
(314.71)
6.86
(174.24)
7.43
(188.72)
54.8
(24.86)
SAE N/A 5.7 2250A

ODP-AGM8D
(8D-1500)
12 2700 1500 2015 1787 220 198 475 20.39
(517.91)
10.87
(276.10)
8.86
(225.04)
143.0
(64.86)
SAE N/A

ODP-AGM65
(65-760)
12 1350 750 1200 891 64 59 129 11.84
(300.74)
7.19
(182.63)
7.56
(192.02)
49.8
(22.59)
SAE N/A 2.3 2500A

ODP-AGM4D
(4D-1300)
12 2400 1300 1747 1549 170 153 370 20.39
(517.91)
8.78
(223.01)
8.58
(217.93)
117.3
(53.21)
SAE 60 (6.8)

ODP-AGM49 H8 L5
(49-950)
12 1700 950 1300 1150 94 85 160 13.89
(352.81)
6.86
(174.24)
7.43
(188.72)
62.8
(28.49)
SAE N/A 4.8 2650A

ODP-AGM48 H6 L3
(48-720)
12 1250 723 950 842 69 63 130 10.92
(277.37)
6.86
(174.24)
7.43
(188.72)
48
(21.77)
SAE N/A 2.8 2300A

ODP-AGM47 H5 L2
(47-650)
12 1150 650 850 750 64 58 105 9.51
(241.55)
6.89
(175.01)
7.43
(188.72)
41.9
(19.01)
SAE N/A

ODP-AGM34R
(34R-790)
12 1300 710 1200 990 61 57 120 10.84
(275.34)
6.77
(171.96)
7.85
(199.39)
46.6
(21.14)
SAE N/A 2.9 2400A

ODP-AGM34 78
(ELT-AGM34/78)
12 1300 710 950 810 60 56 120 10.87
(276.10)
6.75
(171.45)
7.87
(199.90)
46.7
(21.18)
SAE & Side 60 (6.8) side only 4.9 1850A

ODP-AGM34
(34-790)
12 1300 710 1200 990 61 57 120 10.84
(275.34)
6.77
(171.96)
7.85
(199.39)
46.6
(21.14)
SAE N/A 2.9 2400A

ODP-AGM31A
(31-925T)
12 1750 925 1325 1150 100 92 200 12.99
(329.95)
6.79
(172.47)
9.43
(239.52)
69.5
(31.52)
SAE N/A 2.6 2600A

ODP-AGM31
(31-925S)
12 1750 925 1325 1150 100 92 200 12.99
(329.95)
6.79
(172.47)
9.55
(242.57)
69.5
(31.52)
3/8-16" Stud 200 (22.6) 2.6 2600A

ODYSSEY Pro Series Heavy Duty/Commercial batteries

MODEL Voltage PHCA**
(5 sec.)
CCA* HCA MCA Nominal Capacity Reserve Capacity Minutes Length inches
(mm)
Width inches
(mm)
Height inches
(mm)
Weight lbs
(kg)
Terminal Torque Specs in-lbs
(Nm max)
Internal Resistance
(mΩ)
Short Circuit Current
(20 Hr Rate-Ah) (10 Hr Rate-Ah)

NSB-AGM8DS
12 2150 1150 1545 1370 100 92 205 20.36
(517.14)
10.84
(275.34)
9.61
(244.09)
152.3
(69.08)
3/8-16" Stud 200 (22.6) stud only 1.7 6200A

NSB-AGM8D
12 2150 1150 1545 1370 100 92 205 20.36
(517.14)
10.84
(275.34)
9.61
(244.09)
152.3
(69.08)
SAE N/A 1.7 6200A

NSB-AGM65
12 1750 930 1280 1070 69 64 135 11.76
(298.70)
7.32
(185.93)
7.42
(188.47)
54
(24.49)
SAE N/A 3.3 5000A

NSB-AGM34 78
(NSB-AGM34/78)
12 1500 880 1250 1050 65 61 134 10.87
(276.10)
6.75
(171.45)
7.77
(197.36)
50.9
(23.09)
SAE & Side 60 (6.8) side terminal only 3.6 3100A

NSB-AGM34
12 1500 880 1250 1050 65 61 134 10.87
(276.10)
6.75
(171.45)
7.77
(197.36)
50.9
(23.09)
SAE N/A 3.6 3100A

NSB-AGM31A
12 2150 1150 1545 1370 100 92 205 12.91
(327.91)
6.77
(171.96)
9.25
(234.95)
75.2
(34.11)
SAE N/A 2.2 5000A

NSB-AGM31
12 2150 1150 1545 1370 103 98 220 12.91
(327.91)
6.77
(171.96)
9.25
(234.95)
75.2
(34.11)
3/8-16" Stud 200 (22.6) stud only 2.2 5000A

NSB-AGM27F
12 1750 930 1290 1080 92 88 195 12.4
(314.96)
6.77
(171.96)
8.75
(222.25)
67.9
(30.80)
SAE N/A 2.6 5000A

NSB-AGM27
12 1750 930 1290 1080 92 88 195 12.4
(314.96)
6.77
(171.96)
8.75
(222.25)
67.9
(30.80)
SAE N/A 2.6 5000A

NSB-AGM24F
12 1500 840 1200 1000 76 73 160 10.87
(276.10)
6.77
(171.96)
8.75
(222.25)
57.1
(25.90)
SAE N/A 4.5 3100A

NSB-AGM24
wccpf_none 1500 840 1200 1000 76 73 160 10.87
(276.10)
6.77
(171.96)
8.75
(222.25)
57.1
(25.90)
SAE N/A 4.5 3100A
  • *Cold Start Performance S.A.E J537 JUNE 82
  • **Pulse Current
  • † Can be fitted with brass automotive terminal
  • Operating temperature range:
  • -40°C (-40°F) to 80°C (176°F)
  • -30°C (-22 °F) to 40°C (104°F) for PC2250

Optional Height Adapter

Optional height adapter may be used on both 34-PC1500 models for installations where a group 24 or group 27 is required. Snap the adapter securely into place on the bottom of the 34-PC1500 battery. In some installations, either 34-PC1500 model with this adapter may be used to replace a group 24F or 27F depending on required cable length.
